Waldent Smart-LED Curing Light 1500mW
Waldent Smart LED Curing Light comes with ultra mini design. This mini technology of curing dental restorative material has been designed keeping Ergonomics need on top priority. With delayed working hours for dental practioners, there are more chances of developing health related disorders.
Contact us for sales assistance from our Biomedical Engineer.
Multiple options for setting the time , handy, mini designed LED Light Cure Unit makes it easy for the dentist to use optimum time & wavelength required for curing the restorative material
Ideally used for:
Curing Light cure Composite or Glass Ionomer
Features:
1. Ergonomic design
- Elegant design, very convenient for clinical use
- Wireless curing light with charging 5W big power LED
- Noisefree operation
- Uses imported LED, big power, intensity and longevity, energy
- Imported SMOS components, stable, noiseless, no vibration
2. Working Modes
- Three working modes : Strong, Gradually strong, Flashing
3. Intensity
- Light intensity ranges between 1200-1500mW/cm²
- Constant light intensity. The solidification effect is not affected by the consumption of remaining power
4. Efficiency
- It can solidify upto 2-3mm deepth in 5 to 40 Sec
- Can be used Worldwide 100V-240V
- With blue high sensitive brightness, can cure the resin which the wavelength of 420-480nm
5. Battery
- High-capacity lithium battery
- The special design of charger base can be also used for holding the handle
- Low battery alert
| Technical Specification |
PRECAUTION:
|
|---|
- 1 x Main unit
- 1 x Fiber probe
- 1 x Charger with Adapter
- 1 x Light shield
- Instruction manual
Charge the Device:
- Ensure the unit is adequately charged before use.
- Plug the device into a power source using the provided charger.
Power On/Off:
- Power on the unit using the designated button.
- Select the desired working mode (Strong, Gradually Strong, Flashing) based on the procedure requirements.
Position the Light Guide:
- Attach the light guide stick to the device, ensuring proper connection.
Patient and Material Preparation:
- Position the patient comfortably.
- Apply the light-curable dental material as per the specific procedure.
Activate the Light:
- Direct the light guide tip to the area requiring polymerization.
- Press the light activation button to initiate the curing process.
Adjust Duration:
- Set the curing time based on the recommended guidelines for the chosen working mode.
Monitor Curing Process:
- Keep the light guide near the material during the designated curing time.
Power Off:
- Power off the unit after completing the curing process.
Clean and Store:
- Wipe the light guide tip with a clean, alcohol-dampened cloth.
- Store the unit in a designated space, ensuring proper care and maintenance.
